DBSL-SJ 輪輻式傳感器
輪輻式傳感器;優質合金鋼材質;高精度;高穩定性;低外形;安裝簡便、快速;表層鍍鎳防腐處理;適用于試驗機和料斗秤等;

產品特點和優勢
Features主要特點
● Spoke type load cell
● Senior alloy steel
● High accuracy
● High stability
● Low profile
● Easy to install
● Protected against corrosion by nickelplated treatment
● Suitable for testing machine, dynamomete, etc.
● 輪輻式傳感器
● 優質合金鋼材質
● 高精度
● 高穩定性
● 低外形
● 安裝簡便、快速
● 表層鍍鎳防腐處理
● 適用于試驗機和料斗秤等
Capacities量程
0.5t,1t,2t
Specification 技術參數
| Rated Output | 額定輸出 | 2.0mV/V ±0.25% |
| Zero Balance | 零點平衡 | ±1% of rated output |
| Creep after 30 minutes | 蠕變 | ±0.03% of rated output |
| Nonlinearity | 非線性 | ±0.03% of rated output |
| Hysteresis | 滯后 | ±0.03% of rated output |
| Repeatability | 重復性 | ±0.03% of rated output |
| Temp. effect on output | 靈敏度溫漂 | ≤0.002% of applied output/oC |
| Temp. effect on zero | 零點溫漂 | ≤0.002% of rated output/oC |
| Safe Temp. Range | 可用溫度范圍 | -10oC to + 70oC |
| Temp. Compensated | 溫度補償范圍 | -10oC to + 40oC |
| Safe Overload | 安全載荷 | 150% |
| Input Impedance | 輸入阻抗 | 387 ohm ± 20 ohm |
| Output Impedance | 輸出阻抗 | 350 ohm ± 5 ohm |
| Insulation Resistance | 絕緣阻抗 | ≥5000 M ohm (50V DC) |
| Rated Excitation | *激勵電壓 | 10V DC/AC |
| Maximum Excitation | zui大激勵電壓 | 15V DC/AC |
| Cable Length | 導線長度 | 500cm |
| Cable Color Code | 導線顏色 | Red(+E) Black(-E) Green(+S) White(-S) |
